Model RZ-1
Electrical Engine: 1 HP; 2800 RPM; 220/380 V; 50 Hz; Protection IP 55; Metal lined100%.
Suction Lift: 1" 1/2 Ø
Pumping: 1" Ø
Installation: RZ-1-E under fluid level.
                  RZ-1-R over fluid level.
(look pump despiece)

(
look installation planes)
(See the table of chemical resistances)
