Model RZ-4
Electrical Engine: 10 HP; 2800 RPM; 220/660 V; 50 Hz; Protection IP 55; Metal Blinded 100%.
Suction lift: 2" Ø
Pumping: 1 1/2" Ø
Installation: RZ-4-E Under fluid level.
                  RZ-4-R Over fluid level
(look pump despiece)
(look installation planes)
(See the table of chemical resistances)
